Please read the information below and do your own research before you order. This transaxle assembly can be used as is in the models listed below. It could also be modified to fit many other Dixon models with a little bit of knowledge and ingenuity. Also, I have included an entire parts list of what the assembly is made of. Some of you may wish to part this out for other Dixon’s or to re-sell. DIXON R/B 931 INFORMATION. ALTERNATE PART NUMBERS ENTIRE ASSEMBLY =. DIXON 5300, 539129447, 539129434. ENTIRE ASSEMBLY FITS =. PARTS INCLUDED IN THIS ASSEMBLY = (PN, PN, DESCRIPTION, QTY). 1465 1465 PIVOT ARM WELDMENT 1 2166 2166 PIVOT BOLT 1 2172 2172 SWIVEL FITTING 1 3009 3009 5/16-18X1-3/4HHB GR8 1 3012 3012 3/8-16 UNC HEX NUT 1 3048 3048 3/8-16UNCX1 1/2HH BLT 1 3052 3052 PIN, COTTER 3/32 DIA X 1 1 3054 3054 PIN, ROLL 3/16 DIA X 1 1 3074 3074 NUT 5/16-24 UNF HEX JAM 1 3088 3088 1/4-20X1 HHB GR5 1 3118 3118 DISCSPRING. 38 1 3178 3178 3/8-16X2 1/2 HHBG5 1 3182 3182 FLIP-LOK BUSHING 1 3205 3205 5/16-18 HX NUT W/NY. 1 3206 3206 3/8-16UNC HEX L-NUT 1 3209 3209 1/2-20 HEX JAM NUT 1 3232 3232 1 3263 3263 5/8-11 THIN PROF NY 1 3279 3279 SET SCREW W/HEX HEAD 1 3328 3328 5/16-24X1-1/2HHB GR5 1 3334 3334 1/4-20 THIN PROF NY 1 3353 3353 5/16-18X3/4 HB W/LW 1 3354 3354 5/16-18X1-1/2HB W/LW 1 3355 3355 7/16-14 STD HEX NUT 1 3365 3365 1 3578 3578 NYLON BUSHING 1/2 ID 1 3775 3775 DOUBLE BALL JOINT 1 3882 3882 HAND GRIP-NOTCHED 1 5036 5036 PIVOT SPRING 1 ZTR 429 (1993) Page 17 of 21 ZTR 429 (1993) 5056 5056 ALIGNMENT TOOL 1 5070 5070 KEY, 3/16 SQ X. 88 1 5079 5079 PULLEY A 5/8 X 4.0 1 5085 5085 BRAKE BAND 1 5087 5087 SPACER 3/8X12 1 5100 5100 BRAKE ROD 1 5103 5103 R/B 5103 THUMBSCREW 1 5109 5109 CONE (1) 1 5110 5110 SHAFT – CONE FRAME 1 5133 5133 R/B 5133 CRADLE SPRING 1 5139 5139 #3 TOOL(1.0X1.875OD) 1 5152 5152 TORQUE ROD 1 5170 5170 POS SPRYELLOW ZINC CHRO 1 5176 5176 BELCRANK 1 5185 5185 R/B 5185 ADJUSTER TORQUE ROD 1 5189 5189 BUSHING 1 5202 5202 SPACER 5/8 X 1/4 1 5221 5221 POS. NEUTRAL ROD 1 5222 5222 R/B 5352 FRONT TUBE 1 5242 5242 PLUG W/HOLE – FLAT 1 5246 5246 R/B 5246 CHAIN RS40 30P 1 5249 5249 5/8 BEARING W/SNAP 1 5253 5253 CRADLE – MACHINED 1 5254 5254 CONE FRAME-MACHINED 1 5255 5255 R/B 13408 DISCUP 1 5257 5257 BRAKE DRUM 1 5259 5259 24T SPROCKET WLDT 1 5262 5262 CRADLE SHAFT 1 5265 5265 SPACER – 4.325 1 Ref Number Part Number Part Description Context Notes Quantity ZTR 429 (1993) Page 18 of 21 ZTR 429 (1993) 5271 5271 SPACER 3.115 1 5274 5274 MACHINED SUPPORT LH 1 5279 5279 BUSHING, PIVOT 1 5281 5281 R/B 8834 BACKING PLATE WLDT 1 5285 5285 SUPPORT/STOP WLDT 1 5286 5286 SUPPORT WELDMENT 1 5287 5287 BRAKE SHAFT WELDMENT 1 5288 5288 BRAKE ARM DRILLED 1 5297 5297 1 5554 5554 SPACER 1 8215 8215 LEVER ADAPTER KIT 1 8241 8241 HEIGHT GAUGE ASM 1 8256 8256 BEARING DRIVER-TRANS 1 8257 8257 BEARING DRIVER-DECK 1 8258 8258 BEARING PUNCH 1 8259 8259 CRADLE PUNCH 1 8260 8260 HRDWARE PKG-TOOL KIT 1 8261 8261 TRANSAXLE TOOL KIT 1 8413 8413 R/B 8413 SPROCKET – 9T 1.
